Model

JL-03

Model

JL-03

Rated Capacities

50,60,100,150,200,250,300,500,

600,750,800,1000,1200（kg）

Output Impedance

350±5 Ω

Rated Output

2.0 mV/V±5%

Insulation Impedance

≥5000 MΩ

Non-linearity

0.02 %F.S

Safe Overload

150 %F.S

Hysteresis

0.02 %F.S

Ultimate Overload

200 %F.S

Repeatability

0.02 %F.S

Operating Temperature Range

-20~60 ℃

Creep(20min)

0.02 %F.S

Recommended Excitation

5~12 VDC

Temperature Effect On Output

0.002 %F.S/℃

Maximum Excitation

15 VDC

Temperature  Effect On Zero

0.003 %F.S/℃

Construction

Aluminum Alloy

Zero Balance

±0.0200 mV/V

Protection Class

IP66 / IP67

Input Impedance

390±15 Ω；410±15 Ω

Cable

φ5×2 m

Mode of Connection

Red（EXC+）,Black（EXC-）,Green（SIG+）,White（SIG-）
